| MOQ: | 1 |
| 価格: | 2570USD~2770USD |
| 標準パッケージ: | Based on demand |
| 配達期間: | 4~8 work week |
| 決済方法: | T/T |
| 供給能力: | 50PCS/Month |
One of the key features of the Fisher 3620J is its hysteresis, which is 0.75% of the output span. This means that the valve positioner can accurately control valve position and maintain it within the desired range. Additionally, the 3620J is capable of controlling various process control parameters, including flow, pressure, temperature, and level. This makes it a versatile solution for a wide range of applications.
The Fisher 3620J outputs a pneumatic pressure signal as required by the actuator up to full supply pressure. This ensures that the valve positioner can provide precise and reliable control over the valve position, even in high-pressure applications. The 3620J is also equipped with a range of advanced features that make it easy to use and maintain.
Overall, the Fisher 3620J is an excellent choice for anyone looking for a high-quality valve positioner. With its advanced features, accurate control, and reliable performance, the 3620J is a top-of-the-line product that is sure to meet and exceed your expectations. So if you want to take your process control to the next level, be sure to check out the Fisher 3620J today.
This product is a valve positioner, also known as a smart valve positioner or valve position regulator. It has a degree of protection of IP 54/NEMA 3 and a hysteresis of 0.75% of output span. The electrical connection is a 1/2-14 NPT conduit connection, and it can operate within temperature limits of -40 to 82℃.
| Product Type: | Smart Valve Positioner |
| Model Number: | 3620J |
| Operative Temperature Limits: | -40 To 82℃ |
| Electrical Connection: | 1/2-14 NPT Conduit Connection |
| Sensitivity: | A 10% Change In Supply |
| Approximate Weight: | 3.6 Kg (8.0 Pounds) |
| Materials: | Stainless Steel,Copper,Brass ,Low Copper Aluminum Alloy |
| Pressure Connections: | 1/4 NPT Internal |
| Area Classification: | Explosion Proof, Intrinsically Safe, Non-incendive, Dust |
| Output Signal: | Pneumatic Pressure As Required By The Actuator Up To Full Supply Pressure |
| Description: | The Control Valve Positioner is a Smart Valve Positioner designed to accurately control the position of valve actuators. It is suitable for use in hazardous environments and can be classified as Explosion Proof, Intrinsically Safe, Non-incendive, or Dust. The product is made of high-quality materials such as Stainless Steel, Copper, Brass, and Low Copper Aluminum Alloy, ensuring its durability and reliability. With a sensitivity of a 10% change in supply, it can precisely control the valve position. It has an electrical connection of 1/2-14 NPT Conduit Connection and pressure connections of 1/4 NPT Internal. The approximate weight of the product is 3.6 Kg (8.0 Pounds). |
|
|
| MOQ: | 1 |
| 価格: | 2570USD~2770USD |
| 標準パッケージ: | Based on demand |
| 配達期間: | 4~8 work week |
| 決済方法: | T/T |
| 供給能力: | 50PCS/Month |
One of the key features of the Fisher 3620J is its hysteresis, which is 0.75% of the output span. This means that the valve positioner can accurately control valve position and maintain it within the desired range. Additionally, the 3620J is capable of controlling various process control parameters, including flow, pressure, temperature, and level. This makes it a versatile solution for a wide range of applications.
The Fisher 3620J outputs a pneumatic pressure signal as required by the actuator up to full supply pressure. This ensures that the valve positioner can provide precise and reliable control over the valve position, even in high-pressure applications. The 3620J is also equipped with a range of advanced features that make it easy to use and maintain.
Overall, the Fisher 3620J is an excellent choice for anyone looking for a high-quality valve positioner. With its advanced features, accurate control, and reliable performance, the 3620J is a top-of-the-line product that is sure to meet and exceed your expectations. So if you want to take your process control to the next level, be sure to check out the Fisher 3620J today.
This product is a valve positioner, also known as a smart valve positioner or valve position regulator. It has a degree of protection of IP 54/NEMA 3 and a hysteresis of 0.75% of output span. The electrical connection is a 1/2-14 NPT conduit connection, and it can operate within temperature limits of -40 to 82℃.
| Product Type: | Smart Valve Positioner |
| Model Number: | 3620J |
| Operative Temperature Limits: | -40 To 82℃ |
| Electrical Connection: | 1/2-14 NPT Conduit Connection |
| Sensitivity: | A 10% Change In Supply |
| Approximate Weight: | 3.6 Kg (8.0 Pounds) |
| Materials: | Stainless Steel,Copper,Brass ,Low Copper Aluminum Alloy |
| Pressure Connections: | 1/4 NPT Internal |
| Area Classification: | Explosion Proof, Intrinsically Safe, Non-incendive, Dust |
| Output Signal: | Pneumatic Pressure As Required By The Actuator Up To Full Supply Pressure |
| Description: | The Control Valve Positioner is a Smart Valve Positioner designed to accurately control the position of valve actuators. It is suitable for use in hazardous environments and can be classified as Explosion Proof, Intrinsically Safe, Non-incendive, or Dust. The product is made of high-quality materials such as Stainless Steel, Copper, Brass, and Low Copper Aluminum Alloy, ensuring its durability and reliability. With a sensitivity of a 10% change in supply, it can precisely control the valve position. It has an electrical connection of 1/2-14 NPT Conduit Connection and pressure connections of 1/4 NPT Internal. The approximate weight of the product is 3.6 Kg (8.0 Pounds). |
