The Fisher DVC6200 Valve Positioner is an intelligent predictive positioning system that anticipates valve issues before they impact operations. Leveraging ValveSight analytics and HART 7, it monitors friction, deadband, and response time to enable proactive maintenance. The non-contact feedback mechanism provides ±0.75% accuracy for rotary and linear actuators, with modular field-replaceable units ensuring zero downtime. With SIL 3 certification and encapsulated electronics, the DVC6200 is built for the rigors of oil and gas, refining, and pulp and paper, offering predictive intelligence that transforms valve management into a strategic asset.
| Parameter | Specification |
|---|---|
| Input Signal | 4-20 mA HART 7 |
| Supply Pressure | 1.4-10.3 bar (20-150 psig) |
| Accuracy | ±0.75% of span |
| Repeatability | ±0.3% of span |
| Temperature Range | -52°C to +85°C (-62°F to +185°F) |
| Enclosure Rating | IP66/NEMA 4X |
| Certifications | SIL 3, ATEX, IECEx, FM, CSA |
| Air Consumption | 0.28-0.38 Nm³/h |
| Actuator Types | Linear/Rotary, Single/Double-Acting |
| Weight | 3.2 kg (7 lbs) |
ValveSight detects early wear through friction trends.
Yes, with enhanced data capabilities.
Yes, FRU design minimizes downtime.
Up to 5g sinusoidal.
Yes, with NAMUR and standard mounts.
For more information about the Fisher DVC6200 Valve Positioner, pricing, or to request a demo, contact our team:
