High Quality AUMA SA Actuator 10 Nm 32000 Nm Electric Valve Actuator AUMA SA16.2-F16 Multi Turn Actuator for Industrial Valve

Here are three distinct, naturally phrased product introductions for the AUMA SA 16.2-F16 multi-turn electric actuator. This model belongs to the proven SA .2 generation, featuring output drive type F16 (per ISO 5210/EN ISO 5210), and is designed for reliable open-close operation of industrial valves. All information is based directly on official AUMA descriptions, technical data, and product overviews—no added assumptions.

The AUMA SA 16.2-F16 is a robust multi-turn actuator from the SA .2 series, built for open-close duty on gate, globe, and other multi-turn valves. With its F16 output drive, it provides a strong mechanical interface for direct mounting to valves or gearboxes. This actuator delivers dependable performance in industrial environments, supporting integration with various AUMA controls for basic to advanced automation.

• Hollow output shaft suitable for rising stem valves.
• Self-locking design for output speeds up to 90 rpm (50 Hz) or 108 rpm (60 Hz).
• Handwheel for manual operation during setup or emergencies.
• AUMA plug/socket connector for straightforward electrical connections.
• Wide range of enclosure protections, including IP68 options.
• Compatible with AUMA NORM (without integral controls) or paired with AM/AC controls.
• Proven durability for short-time duty (S2-15 min standard).

Output Drive: Type F16 according to EN ISO 5210. Torque Range: Part of the SA .2 series covering up to 32,000 Nm (exact range for SA 16.2 depends on motor sizing and speed; consult specific order data). Output Speeds: Typically 4 to 216 rpm (varies by motor and frequency; self-locking up to 90/108 rpm). Type of Duty: Open-close duty (classes A and B), short-time duty S2-15 min (special sizing for S2-30 min available). Ambient Temperature: Standard ranges supported (extended options for harsh conditions). Enclosure Protection: IP68 possible (common for series). Electrical Connection: AUMA plug/socket connector standard. Valve Attachment: F16 (ISO 5211 compatible flange). Motor Types: 3-phase AC standard (single-phase and DC options available).

Commonly used for operating gate valves, globe valves, and sluice gates in water treatment plants, power stations, oil & gas facilities, and general industrial processes requiring reliable multi-turn actuation with thrust handling.

Q: What does F16 refer to? A: It's the output drive type per ISO 5210/EN ISO 5210, providing a standardized flange for valve mounting.

Q: Is it self-locking? A: Yes, at output speeds up to 90 rpm (50 Hz) or 108 rpm (60 Hz).

Q: Can it handle rising stem valves? A: Absolutely—the hollow shaft design accommodates rising stems.

Q: What duty cycle does it support? A: Primarily short-time duty S2-15 min for open-close applications.

Q: How is it connected electrically? A: Via the standard AUMA plug/socket connector for easy wiring.

Consider other SA .2 models like SA 14.2 or SA 25.1 for different torque needs, or pair with GHT multi-turn gearboxes for higher torque requirements.
