The ASCO JPIS8314B301 24VDC Solenoid Valve is a robust, compact 2-way direct-acting valve engineered for reliable pneumatic control in industrial and commercial systems. Operating on 24VDC, it ensures quick response times and consistent performance for air, gas, and vacuum applications. With a 1/8" NPT port and 1/4" orifice, this valve is ideal for actuation in automation, HVAC, and machinery. Its rugged aluminum body and epoxy encapsulation provide exceptional durability, making it a trusted choice for demanding environments where precision and reliability are paramount.
| Parameter | Specification |
|---|---|
| Model Number | JPIS8314B301 |
| Voltage | 24VDC |
| Valve Type | 2-way direct-acting |
| Port Size | 1/8" NPT |
| Orifice Size | 1/4" (6.4 mm) |
| Operating Pressure | 0-150 psi (0-10 bar) |
| Temperature Range | -10°C to +50°C (14°F to 122°F) |
| Body Material | Aluminum |
| Seal Material | NBR (Nitrile) |
| Power Consumption | 3.5 W |
| Response Time | ≤ 50 ms |
| Certifications | CE, UL |
The ASCO JPIS8314B301 24VDC Solenoid Valve is suited for reliable pneumatic actuation in industrial settings:
≤ 50 ms for quick actuation.
Yes, fails safe when de-energized.
Air, inert gases, vacuum; not for corrosive fluids.
24VDC with 3.5 W consumption.
Contact manufacturer for certified options.
For more information about the ASCO JPIS8314B301 24VDC Solenoid Valve, pricing, or to request a demo, contact our team:
